Yamaha MG Series MG12

Yamaha MG Series MG12

12-Channel Mixing Console: Max. 6 Mic / 12 Line Inputs (4 mono + 4 stereo) / 2 GROUP Buses + 1 Stereo Bus / 2 AUX (incl. FX)

  • 12-Channel Mixing Console
  • Max. 6 Mic / 12 Line Inputs (4 mono + 4 stereo)
  • 2 GROUP Buses + 1 Stereo Bus
  • 2 AUX (incl. FX)
  • “D-PRE” mic preamps with an inverted Darlington circuit
  • 1-Knob compressors
  • PAD switch on mono inputs
  • +48V phantom power
  • XLR balanced outputs
  • Internal universal power supply for world-wide use
  • Optional Rack Mount Kit RK-MG12 Available
  • Metal chassis
  • 308 mm x 118 mm x 422 mm (12.1″ x4.6″ x16.6″)
  • Net Weight: 4.0 kg (8.8 lbs.)

Description

Total Harmonic Distortion:

0.03% @+14 dBu (20 Hz – 20 kHz), GAIN knob: Min, 0.005% @+24 dBu (1 kHz), GAIN knob: Min



Frequency Response:

+0.5/ -1.5 dB (20 Hz to 48 kHz), refer to the nominal output level @ 1kHz, GAIN knob: Min



Crosstalk:

-78 dB



Power Requirements:

AC 100 – 240 V, 50/ 60 Hz



Power Consumption:

22 W



Dimensions:

Width: 308 mm (12.1 )

Height: 118 mm (4.6″)

Depth: 422 mm (16.6″)



Net Weight:

4.0 kg (8.8 lbs.)

Included Accessories:

Owner’s manual

Technical Specifications

AC Power Cord
