Yamaha MG Series MG10XU

Yamaha MG Series MG10XU

10-Channel Mixing Console: Max. 4 Mic / 10 Line Inputs (4 mono + 3 stereo) / 1 Stereo Bus / 1 AUX (incl. FX)

  • 10-Channel Mixing Console
  • Max. 4 Mic / 10 Line Inputs (4 mono + 3 stereo)
  • 1 Stereo Bus
  • 1 AUX (incl. FX)
  • “D-PRE” mic preamps with an inverted Darlington circuit
  • 1-Knob compressors
  • High-grade effects: SPX with 24 programs
  • 24-bit / 192kHz 2in / 2out USB Audio functions
  • Works with the iPad (2 or later) through the Apple iPad Camera Connection Kit / Lightning to USB Camera Adapter
  • Includes Cubase AI DAW software download version
  • PAD switch on mono inputs
  • +48V phantom power
  • XLR balanced outputs
  • Metal chassis
  • Dimensions(W×H×D): 244 mm x 71 mm x 294 mm (9.6″x 2.8″x 11.6″)
  • Net Weight: 2.1 kg (4.63 lbs.)

Description

Total Harmonic Distortion:

0.02% @+14 dBu (20 Hz – 20 kHz), GAIN knob: Min, 0.003% @+24 dBu (1 kHz), GAIN knob: Min



Frequency Response:

+0.5/ -1.0 dB (20 Hz to 48 kHz), refer to the nominal output level @ 1kHz, GAIN knob: Min



Crosstalk:

-83 dB



Power Requirements:

PA-10 (AC 38 VCT, 0.62A, Cable length = 3.6 m) or equivalent recommended by Yamaha



Power Consumption:

22.9 W



Dimensions:

Width: 244 mm (9.6 )

Height: 71 mm (2.8″)

Depth: 294 mm (11.6″)



Net Weight:

2.1 kg (4.63 lbs.)

Included Accessories:

AC Adaptor

Owner’s manual

Cubase Al Download Information
