Epson EB-L790SE Short Throw 3LCD Laser Projector with 4K Enhancement

The exceptionally bright short throw laser display with a 0.79 – 1.36 throw ratio and 4K Enhancement.
Experience the extraordinary versatility and performance of our bright and compact L-Series. Expanding on the possibilities of this powerful projector lineup, the high-lumen EB-L790SE features an expansive 0.79 – 1.36 throw ratio and a large display up to 400″. With wide vertical and horizontal lens shifts and 1.7x optical zoom, the projector is ideal for a wide variety of applications, such as conference rooms, hybrid workspaces, golf simulation, museum exhibitions and more. Deliver ultra bright images in rooms with high-ambient light with 7,000 lumens of equal color and white brightness and 4K Enhancement Technology that displays double HD resolution on screen.

Simple to install, the EB-L790SE is easy to operate from start to finish. Built-in NFC functionality, wide lens shift, 360-degree mounting, geometric correction tools and more allow for simple, seamless integration. Created with convenience in mind, the projector features an up to 30,000-hour virtually maintenance-free laser light source4 and air filter in Extended Mode. Plus, it’s built for modern connectivity with fast wireless functionality for screen casting and PC-less remote management and control via the Epson Projector Management Connected app. In addition, simplify complex multi-projector applications with the optional attachable ELPEC01 camera.

7,000 lumens color/white brightness
WUXGA with 4K Enhancement for clear, detailed images
0.79 to 1.36 throw ratio and 1.7x optical zoom
Display up to 400″ diagonal in 16:10, plus ultra wide 16:6 and 21:9
Lightweight, compact design allows for easy installation
AirPlay 2 supported

Category:

Description

Ultra bright, true-to-life images
3-chip 3LCD technology and 7,000 lumens of equal color and white brightness

WUXGA with 4K Enhancement Technology
Accepts 4K content and displays double HD resolution on-screen; enjoy a visibly sharper, more detailed picture even at close viewing distances

Large, versatile display options
Easily create a display up to 500″ diagonal in 16:10, plus ultra wide 16:6 and 21:9 aspect ratios for enhanced content display and visibility

Simplified installation
Compact and lightweight design featuring a wide vertical and horizontal lens shift, 1.7x optical zoom, 360-degree mounting, built-in geometric correction tools and a universal VESA mounting pattern

Low maintenance
Up to 30,000-hour laser light source and air filter in Extended Mode

Wireless networking and content sharing
Wi-Fi 6 allows for fast, reliable wireless connectivity for screen casting, along with direct connection to the cloud-based service, Epson Projector Management Connected, and WPA 3-enterprise security

FeatureSpecification
Projection TechnologyRGB liquid crystal shutter projection system (3LCD)
Brightness7,600 lm / 7,000 lm / 4,900 lm / 7,000 lm
USB Interface Type A2x (5V/2A and 5V/0.9A)
USB Interface Type B1x (Firmware, Copy OSD Settings)
Wired LANRJ45 x 1 (100Mbps)
Wireless LANBuilt-in
HDMI Input2 (HDCP 2.3)
HDBaseT Input1 (HDCP 2.3)
Audio OutputStereo Mini: 1
RS-232C Control1 (D-Sub 9pin)
HDMI Output1 (HDCP 2.3, HDMI1 only)
Contrast RatioOver 5,000,000:1
Standard Projection Distance (100″)1.08m – 1.54m
Screen Size (Zoom: Wide)60″ – 400″ (1.02 – 6.95m)
Screen Size (Zoom: Tele)60″ – 400″ (1.75 – 11.89m)
Keystone Correction±30° / ±30°
Projection Orientation360º Free
Operating Temp (Single Use, Low/High Altitude)0-45°C / 0-40°C
Operating Temp (Multi Use, Low/High Altitude)0-40°C / 0-35°C
Operating Altitude0 – 3,048m (High Altitude Mode)
Start-Up Period12 sec (logo), 30 sec (warm-up)
Quick Start-Up<8 sec (Display)
Cool Down PeriodInstant Off
Internal Speaker Output10W Mono
Direct Power On/OffYes
WeightApprox. 9.3kg
Air Filter TypeElectrostatic Filter
Air Filter Maintenance Cycle20,000 hrs / 30,000 hrs
Fan Noise (Normal/Eco)36dB / 26dB
Projection MethodFront / Rear / Ceiling
Projection System3LCD Reflective, Poly-silicon TFT
Pixel Number1920 × 1080 × 3
Color Brightness1500 lumens
Projected OutputHD, 2D, 3D, 1080p
White Brightness1500 lumens
Aspect Ratio16:9 Native
Driving Method0.74-inch Reflective HTPS
Native Resolution1920 × 1080
Laser TypeLaser Diode 41.9 mW
Light Source LifeUp to 20,000 hrs (ECO)
Power Supply Voltage100 – 240 V AC ±10%, 50/60 Hz
Power Consumption (Normal/Extended)450W / 330W
Standby Power (Normal/Eco)2.4W / 0.4W
Colour ModesMultiple (Dynamic, Cinema, etc.)
Dimensions (WxDxH)440 x 304 x 122mm
Miracast CertificationWi-Fi CERTIFIED Miracast R2
Miracast CodecH.264 (AVC)
Wireless ModesInfrastructure, Simple AP
Wireless SpeedIEEE 802.11a/b/g/n/ac/ax
Wireless SecurityOPEN, WPA2/WPA3-PSK/EAP, WPA2-PSK (AES)
AirPlay 2 CodecH.264, H.265, AV1, VP9, MPEG-2/4
