Epson EB-L790U WUXGA 3LCD Laser Projector

Experience an incredibly bright and compact projector with pro-level features.
The Epson EB-L790U adds incredible brightness and pro features to the compact and versatile Epson business projector family. Featuring an impressive 7,300 lumens of color and white brightness , it is ideal for classrooms and lecture halls, conference rooms, hybrid workspaces and more. This powerful projector produces exceptionally vibrant, high-resolution images up to 500” in 16:10, plus is capable of projecting in a variety of other aspect ratios, including ultra wide 16:6 and 21:9.

Designed with convenience in mind, the EB-L790U features an up to 30,000-hour virtually maintenance-free laser light source and air filter in Extended Mode. And for simple, seamless installation, this versatile solution offers a variety of powerful features, such as optical zoom, wide lens shift, geometric correction tools and more. With built-in wireless communication, you can monitor and control your fleet remotely from a web browser using the Epson Projector Management Connected app, as well as enable advanced screen casting tools like Epson iProjection and Miracast. In addition, simplify complex multi-projector applications with the optional attachable ELPEC01 camera.

7,300 lumens color/white brightness
WUXGA resolution for clear, detailed images
Display up to 500″ diagonal in 16:10, plus ultra wide 16:6 and 21:9
Lightweight, compact design allows for easy installation
Up to 30,000-hour laser light source and air filter
AirPlay 2 supported

Description

Ultra bright, true-to-life images

3-chip 3LCD technology and 7,300 lumens of equal color and white brightness

WUXGA resolution

Provides 1920 x 1200 resolution for vibrant, high-definition images

Large, versatile display options

Easily create a display up to 500″ diagonal in 16:10, plus ultra wide 16:6 and 21:9 aspect ratios for enhanced content display and visibility

Simplified installation

Compact and lightweight design featuring a wide vertical and horizontal lens shift, 1.6x optical zoom, 360-degree mounting, built-in geometric correction tools and a universal VESA mounting pattern

Low maintenance

Up to 30,000-hour laser light source and air filter in Extended Mode

Wireless networking and content sharing

Wi-Fi 6 allows for fast, reliable wireless connectivity for screen casting, along with direct connection to the cloud-based service, Epson Projector Management Connected, and WPA 3-enterprise security

FeatureSpecification
Projection TechnologyRGB liquid crystal shutter projection system (3LCD)
Brightness7,900 lm / 7,300 lm / 5,110 lm / 7,300 lm
USB Interface Type A2x (5V/2A and 5V/0.9A)
USB Interface Type B1x (Firmware, Copy OSD Settings)
Wired LANRJ45 x 1 (100Mbps)
Wireless LANBuilt-in
HDMI Input2 (HDCP 2.3)
HDBaseT Input1 (HDCP 2.3)
Audio OutputStereo Mini: 1
RS-232C Control1 (D-Sub 9pin)
HDMI Output1 (HDCP 2.3, HDMI1 only)
Contrast RatioOver 5,000,000:1
Standard Projection Distance (80″)2.33m – 3.78m
Screen Size (Zoom: Wide)50″ – 500″ (1.44 – 14.76m)
Screen Size (Zoom: Tele)50″ – 500″ (2.35 – 23.84m)
Keystone Correction±30° / ±30°
Projection Orientation360º Free
Operating Temp (Single Use, Low/High Altitude)0-45°C / 0-40°C
Operating Temp (Multi Use, Low/High Altitude)0-40°C / 0-35°C
Operating Altitude0 – 3,048m (High Altitude Mode)
Start-Up Period12 sec (logo), 30 sec (warm-up)
Quick Start-Up<8 sec (Display)
Cool Down PeriodInstant Off
Internal Speaker Output10W Mono
Direct Power On/OffYes
WeightApprox. 8.2kg
Air Filter TypeElectrostatic Filter
Air Filter Maintenance Cycle20,000 hrs / 30,000 hrs
Fan Noise (Normal/Eco)34dB / 25dB
Projection MethodFront / Rear / Ceiling
Projection System3LCD Reflective, Poly-silicon TFT
Pixel Number1920 × 1080 × 3
Color Brightness1500 lumens
Projected OutputHD, 2D, 3D, 1080p
White Brightness1500 lumens
Aspect Ratio16:9 Native
Driving Method0.74-inch Reflective HTPS
Native Resolution1920 × 1080
Laser TypeLaser Diode 41.9 mW
Light Source LifeUp to 20,000 hrs (ECO)
Power Supply Voltage100 – 240 V AC ±10%, 50/60 Hz
Power Consumption (Normal/Extended)399W / 295W
Standby Power (Normal/Eco)2.4W / 0.4W
Colour ModesMultiple (Dynamic, Cinema, etc.)
Dimensions (WxDxH)440 x 304 x 122mm
Miracast CertificationWi-Fi CERTIFIED Miracast R2
Miracast CodecH.264 (AVC)
Wireless ModesInfrastructure, Simple AP
Wireless SpeedIEEE 802.11a/b/g/n/ac/ax
Wireless SecurityWPA2/WPA3-PSK/EAP, WPA2-PSK (AES)
AirPlay 2 CodecH.264, H.265, AV1, VP9, MPEG-2/4
