Epson EB-PU1006W WUXGA 3LCD Laser Projector with 4K Enhancement

Premium, compact large venue laser projector with 4K Enhancement.

A sleek powerful projector boosting 6000 lumens of equal colour and white brightness and is designed to be virtually maintenance-free.

This compact and versatile high brightness projector with optional interchangable lens including a zero-offset ultra short throw lens offers flexibility in a wide variety of environments. With its beyond Full HD WUXGA resolution and 4K Enhancement Technology (1920 x 1200 x 2), expect stunning, crystal-clear, true to life images with exceptional image detail and clarity. With the Built-in NFC function, diagnostics and installations is made easier using the Epson Projector Config Tool, reducing the time spent even for the setting up of multiple projectors. The optional external camera module allows access to powerful automated tools including auto color calibration5, screen matching of multiple projectors, Geometry Correction Assist for Tilting for Edge Blending, and Geometry Correction Assist for Stacking function.

  • 6000 lumens Colour and White brightness
  • 4K Enhancement Technology with HDR support
  • Laser light source — up to 20,000 hours of use
  • Compatible with wide range of up to 11 optional powered lenses
  • Advanced installation tools : Free software tools and optional ELPEC01 external camera module


Revolutionary 4 in 1 Laser Package
Equipped with this new laser package, EB-PU1006W delivers 6000 lumens of equal white and colour brightness in a compact, lightweight chassis. This allows for easier and more discreet installations as well as increased transportability.


Borderless Multi Projection
With a wide variety of functions available for multi-projector installations, you can adjust the brightness, colour and position of overlapping areas for seamless, beautiful displays with the PU-series of projectors.

Epson Projector Config Tool for Easy Set Up
Using NFC wireless communications technology to change projector settings and check equipment information, the Epson Projector Config Tool is an app that allows you to configure network and projection settings in advance, even when the projector is switched off. Allowing management across your fleet of projectors, this tool helps to reduce time and effort required, increasing efficiency.


Projection TechnologyRGB liquid crystal shutter projection system (3LCD)
LCDSize0.76″ (C2 Fine)
ResolutionWUXGA (Support 4K Enhancement)
Aspect Ratio16:10
Projection LensTypePower Zoom, Power Focus
F-Number1.7 – 2.3
Focal Length24 – 38.2 mm
Zoom Ratio1.0 – 1.60
Throw Ratio1.44 – 2.32 (Wide – Tele)
Lens ShiftVertical: ±67% (Powered)
Horizontal: ±30% (Powered)
LightsourceTypeLaser Diode
Life20,000 hours (Normal) / 30,000 hours (Extended)
Zoom: Wide50” – 1,000” [1.53 – 31.57 m]
Zoom: Tele50” – 1,000” [2.48 – 50.44 m]
White Light Output6,000 lm / 7,000 lm
Colour Light Output (Normal)6,000 lm
Light Output (Center)6,500 lm
Contrast Ratio
Keystone Correction
Over 2,500,000:1
Projection Orientation360º Free
Vertical / Horizontal±45º / ±30º
Analog RGB Input
D-Sub 15Pin1
Digital InputSDI
HDMI1 (HDCP 2.3)
DVI-D1 (HDCP 1.4)
HDBaseT1 (HDCP 2.3)
USB InputUSB Type A2 (Port1 for 5V/2A Power Supply, Grackle, SMF1, Firmware Update, Copy OSD Settings, Content
Playback ; Port2 for 5V/900mA Power Supply, Wireless LAN, Firmware Update, Copy OSD
Settings, Content Playback)
USB Type B1 (For Firmware Update, Copy OSD Settings)
Control I/ORS-232CD-Sub 9pin x 1
Digital OutputSDI
Audio OutputStereo Mini1
NetworkWired LANRJ45 x 1 (100Mbps)
Optional WirelessELPAP11
Supported Speed for Each mode Infrastructure:
IEEE 802.11b (2.4GHz): 11 Mbps*3, IEEE 802.11g (2.4GHz): 54 Mbps*3, IEEE 802.11n (2.4GHz):
72.2 Mbps*3, IEEE 802.11a (5GHz): 54 Mbps*3, IEEE 802.11n (5GHz): 150 Mbps*3
Access Point (Wi-Fi Direct):
IEEE 802.11g (2.4GHz): 54 Mbps*3, IEEE 802.11n (2.4GHz): 72.2 Mbps*3, IEEE 802.11a (5GHz):
54 Mbps*3, IEEE 802.11n (5GHz): 150 Mbps*3
Supported ModeInfrastructure, Access Point (Wi-Fi Direct)
Supported Security TypeInfrastructure: Open, WPA2 / WPA3-PSK, WPA2 / WPA3-EAP
Supported EAP Type: PEAP, PEAP-TLS, EAP-TLS, EAP-Fast
Access Point (Wi-Fi Direct): WPA2-PSK (AES)
Operating Temperature Single Use Low Altitude (0 – 2,286m/7,500ft): 0 – 45 °C <32 - 113 °F>
High Altitude (Over 2,286m/7,500ft): 0 – 40 °C <32 - 104 °F> 20% – 80% Humidity, No Condensation
Operating AltitudeOver 1,500m/4,921ft with High Altitude Mode: 0 – 3,048m (0 -10,000ft)
Direct Power On / OffYes
Start-Up PeriodLess than 7 seconds (Epson Logo); Warm-up Period: 30 sec
Quick Start-UpLess than 7 seconds (Display)
Cool Down PeriodInstant Off
Air FilterTypeElectrostatic Filter
Maintenance Cycle20,000 hours (Normal) / 30,000 hours (Extended)
Laser Diode On Normal367 W
Extended310 W
Standby (Normal / Eco)Standby (Normal / Eco)2.0 W / 0.5 W
Dimension Excluding Feet (D X W X H)436 x 545 x 164 mm
WeightApprox. 15.4kg
Fan Noise (Normal / Medium / Eco)30dB / 29dB / 28dB
