Marantz AV8805A

The versatile Marantz AV8805A pre-amplifier redefines the audiophile home cinema and music listening experience with 13.2 channel processing capability, 8K pass-through, and support for the latest in surround sound audio formats, such as Dolby Atmos®, DTS:X®, DTS:X® Pro, IMAX Enhanced®, and Auro-3D®. Marantz’ proprietary technologies enhance any audio playback for the most demanding of listeners. Stream music throughout your home with HEOS® Built-in for a whole home audio experience from your favorite streaming services. With the new Marantz AV8805A, you get incredible fidelity and unparalleled audio precision.

  • 8K/60Hz and 4K/120Hz pass-through support for every entertainment need
  • Ideal for the most advanced home theater enthusiast
  • Featuring the most advanced 3D audio formats
  • Enhanced Audio Return Channel (eARC) HDMI support
  • DTS:X® Pro support
  • Bringing you leading edge video compatibility
  • Experience the next chapter in movie entertainment
  • The latest in gaming thrills
  • Stream music from your favorite sources
Categories: ,


Sound Enhancements
Copper Plated ChassisYes
Power Transfomer: Toroidal / ElYes / No
Pure DirectYes
Gold plated RCA terminalsYes
Clock Jitter ReducerYes
AudysseyMultEQ XT32
HEOS Multi-room and StreamingYes
Bluetooth Re-transmit for Bluetooth headphonesNo
Network Audio SharingYes
DSD Audio StreamingYes (2.8/5.6MHz)
Ethernet PortsYes
HDCP2.3 supportYes
Analogue to HDMI scalingup to 8K 60/50
HDMI to HDMI Scalingup to 8K 60/50
HDMI Pass-Through in Standby ModeYes
Multi-Room CI
HEOS Multi-Toom IntegratedYes
Multi-Room Zones3
DC Trigger Output2
FL Display2 lines + port hole
Variable Cross OverYes
ECO ModeNo
Auto Power offYes
Sleep TimerYes
Composite In /Out4+1 / 2
Component In / Out3 / 1
HDMI In / Out7 + 1 / 3
System Remote ControlRC039SR
Power Consumption90W
Power Consumption No-Sound (ECO on/off)No
Standby Consumption0.2W
CEC Standby Consumption0.5W
Network Standby Consumption3.5W
Network Control on ConsumptionNo
Dimensions (W x H x D)Antenna (Horizontal): 439.42 x 185.42 x 459.74mm (17.3" x 7.3" x 18.1")
Antenna (Vertical): 439.42 x 248.92 x 459.74mm (17.3" x 9.8" x 18.1")
W/o Antenna: 439.42 x 185.42 x 459.74mm (17.3" x 7.3" x 17.7")
Weight13.79 kg (30.4 lbs)
