Yamaha RX Series AV Receivers RX-V6A

Get more from your entertainment. With crystal clear images and immersive sound, the V6A makes every moment feel real.

  • 7.2 Channel powerful surround sound with Zone2
  • Wi-Fi, Bluetooth®, AirPlay 2, Spotify Connect and MusicCast multi-room audio
  • Dolby Atmos® with height virtualization via future update
  • HDMI™ 7 in/1 out
  • Dedicated gaming function(ALLM,VRR,QMS,QFT) via future update
  • Voice control with Alexa and Google Assistant devices. *Availability varies by region

Description

Make every night movie night. In fact, feel like you've entered the story. The Yamaha approach to tonal balance delivers incredibly detailed and accurate timbre in each voicing. Dynamism is found in the emotive contrast between the stillness and motion in the movie. The urgency and suspense between action scenes is palpable through the sound field that is created.



This unique Yamaha proprietary sound field creation technology, was created by combining measured sound field data with digital signal processing. Yamaha collected sound field data from famous concert halls and music clubs around the world, utilizing its wealth of experience in the fields of concert hall design, public address and mixing. By digitizing this vast trove of information and incorporating it into dedicated LSI devices, it effectively reproduces the spaces of concert halls and music clubs in your home. Immerse yourself in the astounding realism of your movies, and enter a world of profound theater sound.



It would contribute a precise signal transmission, especially suitable for high resolution audio signal. Generally high slew rate amplifier causes unstable signal transmission, Yamaha’s newly design circuit achieves high slew rate with stable signal transmission.



When music is encoded into a digitally compressed format like MP3, the frequency response suffers. Yamaha’s Compressed Music Enhancer employs sophisticated digital signal processing using exclusive algorithms to restore what was lost, so the music always sounds the way it should.

Amplifier SectionChannel7.2
Rated Output Power (1kHz, 1ch driven)125 W (8 ohms, 0.9% THD)
Rated Output Power (20Hz-20kHz, 2ch driven)100 W (8 ohms, 0.06% THD)
Maximum Effective Output Power (1kHz, 1ch driven)150 W (8 ohms, 10% THD)
High Slew Rate AmplifierYes
Surround Sound ProcessingSurround:AIN/A
CINEMA DSPYes
DSP Programs17
Dialog Level AdjustmentYes
Virtual Presence SpeakerYes
Virtual Surround Back SpeakerYes
Dialogue LiftYes
SILENT CINEMA / Virtual CINEMA DSPYes
Dolby AtmosYes
Dolby Atmos Height VirtualizerYes
Dolby TrueHDYes
Dolby Digital PlusYes
Dolby SurroundYes
DTS:XYes
DTS-HD Master AudioYes
Audio FeaturesFile FormatMP3 / WMA / MPEG-4 AAC: up to 48 kHz / 16-bit, ALAC: up to 96 kHz / 24-bit, FLAC: up to 384 kHz / 24-bit, WAV / AIFF: up to 384 kHz / 32-bit, DSD: up to 11.2 MHz
Pure DirectYes
Compressed Music EnhancerYes
High-resolution Music EnhancerN/A
YPAO multi-point measurementYes
YPAO VolumeYes
Adaptive DRC (Dynamic Range Control)Yes
Initial Volume & Maximum Volume SettingYes
A.R.T. WedgeN/A
Bi-amp capabilityYes
Audio DelayYes (0-500 ms)
DA Converter384 kHz / 32-bit BB PCM5102A
Video FeaturesHDMI eARCYes
HDMI Audio Return ChannelYes
HDMI Pass-through8K60B, 4K120AB, 24GBPS *HDMI1-3
HDMI Up-scalingYes up to 4K
HDMI Up-conversionN/A
Dolby VisionYes
HDR 10+Yes
VRR/ALLM/QMS/QFTYes (via future update)
Video adjustmentN/A
ConnectivityMusicCast SurroundYes
HDMI Input/Output7 / 1
HDMI CECYes
USB InputYes
Network PortYes
Wi-FiYes (2.4 / 5 GHz)
AirPlay 2Yes
BluetoothYes (SBC / AAC)
Front AV InputUSB
Digital Audio Input/Output: Optical1 / 0
Digital Audio Input/Output: Coaxial1 / 0
Analog Audio Input/Output4 / 0
Phono InputYes
XLR TerminalN/A
Component Video Input/OutputN/A
Composite Video Input/OutputN/A
Preout2.2-ch
Headphone Output1
Tuner SectionFM/AM TunerYes (Availability varies by region.)
DAB TunerYes (Availability varies by region.)
User InterfaceOn-screen displayGraphical User Interface
SCENEYes (8 sets)
App ControlYes (iPhone / iPad / Android phone / tablet)
Web Browser ControlYes
Remote Control UnitYes
Zone ControlZone 2 Audio OutputPreout
Zone 3 Audio OutputN/A
Zone 4 Audio OutputN/A
Powered ZoneZone 2
Zone Video OutputN/A
Zone B OutputN/A
Zone GUIN/A
RS-232C InterfaceN/A
+12V Trigger Output1
Remote (IR) Input/OutputN/A
Party ModeYes
GeneralStandby Power Consumption (IR only)0.1 W
Auto Power StandbyYes
ECO modeYes
Dimensions (W x H x D)435 W x 171 H x 377 D mm (with antenna up:435W x 245H x 377D mm);17-1/8"W x 6-3/4"H x 14-7/8"D (with antenna up:17-1/8"W x 9-5/8"H x 14-7/8"D)
Weight9.8 kg; 21.6 lbs.
