Epson EB-L210SF Wireless Full HD Short Throw Laser Projector

Epson EB-L210SF Wireless Full HD Short Throw Laser Projector

Lamp-free laser display for the classroom projects easy-to-read images up to 125″

Change the way you think about classroom displays with the EB-L210SF. Delivering 4,000 lumens of color and white brightness and high-quality Full HD 1080p resolution at up to 125″ diagonal size—more than three times larger than a 75″ flat panel—this short throw lamp-free laser display brings stunning clarity to presentations and encourages engagement with large, bright and easy-to-read images from nearly anywhere in the classroom. Engineered for reliability, this display has a 20,000-hour, virtually maintenance-free laser light source, so there are no lamps to replace—ever. Sharing your lesson plans just got easier with wireless connectivity from PCs, Mac® computers, Chromebooks, and Android™ and iOS® devices, as well as split screen functionality to display up to four devices simultaneously. You can project brilliant images, inspire collaboration and enjoy ease of use with the EB-L210SF—all at a remarkable value.

  • 4,000 lumens of colour and white brightness
  • Full HD 1080p resolution for images up to 125″
  • 20,000-hour lamp-free laser light source
  • Images more than three times larger than a 75″ flat panel
  • Instant-on laser light source
Categories: , , , , ,

Description

Product Brochure
High brightness

With powerful brightness of up to 4,000 lm, EB-L210SF delivers clear and detailed images even in bright environments.


Massive, wide clear content for a full, uncompromised learning/ meeting experience at a short throw distance

Enjoy a dynamic wide screen viewing experience with our short-throw model – EB-L210SF. Projecting up till 119″ for 21:9 aspect ratio, our EB-L210SF allows users to experience all learning contents and interaction all at the same time – virtual meeting or hybrid learning.


High image quality

Delivering exceptional clarity at Full HD resolution, EB-L210SF ensures visual quality while maintaining a short throw distance.


One projector, multiple possibilities

An adaptable piece that serve your every needs, EB-L210SF powers it up to put your statement pieces in the limelight, from projection signage at your reception to sharing your business-shaping ideas.


Projection TechnologyRGB liquid crystal shutter projection system
LCDSize0.62” (C2Fine)
ResolutionFull HD (1080p)
Projection LensTypeNo Optical Zoom / Focus (Manual)
F-Number1.60
Focal Length6.4mm
Zoom Ratio1.0 – 1.35 (Digital Zoom)
Throw Ratio0.45 – 0.61
Light SourceTypeLaser Diode
Light Source Life (Normal/ Quiet/ Extended)20,000 / 20,000 / 30,000 hrs
Zoom: Wide55″ to 125″ [54 cm to 127 cm]
White Light Output (Normal/Extended)4,000lm / 2,800lm
Colour Light Output4,000lm
Contrast RatioOver 2,500,000:1
Sound Output16W Monaural
Vertical / Horizontal Keystone±15º / ±15º
Analog InputD-Sub 15Pin2
CompositeRCA x 1 (Yellow)
Digital InputHDMI2 (HDCP 2.3)
Audio InputRCA (White, Red)1
Stereo Mini Jack2
USB InputUSB Type A1 (For PC Free, Firmware Update, Copy OSD Settings or 5V/2A Power Supply)
USB Type B1 (for Firmware Update, Copy OSD Settings)
Control I/ORS-232CD-Sub 9pin x 1
Analog OutputD-Sub 15Pin1 (Black) (in common with Computer 2)
Audio OutputStereo Mini Jack1
Mic I/OMic In1 (Stereo Mini)
NetworkWired LANRJ45 x 1 (100Mbps)
WirelessBuilt-in and Optional wireless (using ELPAP11)
Supported Speed for Each modeInfrastructure:
IEEE 802.11b (2.4GHz): 11 Mbps
IEEE 802.11g (2.4GHz): 54 Mbps
IEEE 802.11n (2.4GHz): 72.2 Mbps
IEEE 802.11a (5GHz): 54 Mbps
IEEE 802.11n (5GHz): 150.0 Mbps
IEEE 802.11ac (5GHz): 325Mbps
Supported ModeAccess Point (Wi-Fi Direct)
Operating Temperature0 – 2286m (0-7500ft)0°C – 40°C (32°F – 104°F); 20%-80% Humidity, No Condensation
Over 2286m(7500ft)0°C – 35°C (32°F – 95°F); 20%-80% Humidity, No Condensation
Operating AltitudeOver 1,500 m / 4,921 ft, with High Altitude Mode: 0 – 3,048 m (0 – 10,000 ft)
Direct Power On / OffYes
Start-Up PeriodLess than 9 seconds (Epson logo), Warm-up Period: 30 seconds
Quick Start-UpLess than 5 seconds (Display)
Cool Down PeriodInstant Off
Air FilterTypeElectrostatic Filter
Maintenance Cycle20,000 hours
Power Supply Voltage100 – 240 V AC ±10%, 50/60 Hz
Power Consumption (220 – 240V)LD On (Normal / Extended)260W / 191W
Standby (Network On / Off)2.0W / 0.5W
Dimension Excluding Feet (D x W x H)337 x 325 x 90 mm
Weight (with cable cover)Approx. 4.6kg
Fan Noise (Normal / Eco)37dB / 27dB
