Description
- Specifications
Features | |
Number of Channels | 5 |
Power Transformer | Large Capacity EI |
Discrete Amplification | Yes |
Digital Signal Processing | No |
In/Outputs | |
Main-Amplifier In | Balanced & Unbalanced: 5ch (Exclusive use by a selector switch.) |
Multi-Channel In | No |
Networking | No |
DC Triggers | 1 In / 1 Out |
D-Bus Remote (RC-5) In/Out | 1 – 1 |
Specifications | |
Rated Power Output | 140W/ch, 8Ω (20Hz-20kHz, 0.08%) 170 W/ch, 6Ω (20 Hz to 20 kHz/THD = 0.08 %) |
Maximum Effective Output Power | 210W/ch, 6Ω (1 kHz, two channels driven) |
S/N Ratio (IHF-A) | 105dB |
Freq. Response (Analog In) | 8Hz-100kHz (+/- 3dB) |
Freq. Response (Dig In) | No |
Output bandwidth (8 Ω load, 0.09 %) | 5Hz-40kHz |
Damping factor | 100 |
Frequency Range | No |
General | |
Color | Black |
Power Requirement | No |
Power Consumption | 660W (Standby: 0.2W) |
Dimensions (W x H x D) | 440 x 183 x 384mm |
Weight | 15.7kg (34.6 lbs) |
