Yamaha AVENTAGE AV Receiver RX-A4A

The A4A delivers realistic sound and video that transports you out of your home and into your favorite movie. Whether you’re watching, listening, or gaming, you’ll feel completely immersed.

  • 7.2 Channel powerful surround sound with Zone2
  • Wi-Fi, Bluetooth®, AirPlay 2, Spotify Connect and MusicCast multi-room audio
  • SURROUND:AI automatically optimises the surround effect in real time
  • Dolby Atmos® and DTS:X® with CINEMA DSP HD3
  • YPAO™-R.S.C. with multi-point measurement, precision EQ and low frequency mode
  • HDMI™ 7 in/3 out, 8K/60Hz, 4K/120Hz, HDR10+
  • Dedicated gaming function (ALLM, VRR)
  • ESS SABRE ES9007S Premier Audio DAC for high performance conversion
  • Voice control with Alexa and Google Assistant devices. *Availability varies by region

Description



Make every night movie night. In fact, feel like you've entered the story. The Yamaha approach to tonal balance delivers incredibly detailed and accurate timbre in each voicing. Dynamism is found in the emotive contrast between the stillness and motion in the movie. The urgency and suspense between action scenes is palpable through the sound field that is created.





AI technology built into the DSP analyses the scene of the entertainment content and then creates the optimal surround effect to reproduce it with the ultimate impact. This AI instantaneously analyses scenes by focusing on distinct sound elements such as dialogue, background music, ambient sounds and sound effects, and automatically optimizes the surround effect in real time. Imagine having a Yamaha sound engineer right there whilst your listening, tuning the best sound live and specifically for you. AI technology creates a compelling sense of realism with expressive power beyond conventional sound field effects, giving you the most profound entertainment experience possible. Qualcomm® QCS407 with 64-bit high precision processing delivers precise surround sound.





Yamaha’s flagship 3D sound field playback technology was created by combining actually measured sound field data with cutting edge digital signal processing technology. The revamped CINEMA DSP HD3 features new signal processing algorithms and maximises theatre sound effects, accurately reproducing a new dimension of realism for a sound field with a rich sense of presence and no feeling of boundaries. By using front, centre and surround speakers to create a rear virtual speaker, CINEMA DSP HD3 playback up to 11.1 channels is possible* even with a 7.1-channel speaker configuration.

*Requires connection to a front presence speaker.





For those without in-ceiling or upward firing speakers in their system, Dolby Atmos with Height Virtualization Technology simulates the Atmos experience with forward facing-drivers. Configure up to five speakers to replicate the effect of two in-ceiling speakers, or utilize all seven channels to simulate the powerful effect of four overhead speakers.

Feel every dimension in Dolby Atmos. Enjoy a 5.1 surround speaker system and two additional overhead speakers or two Dolby Atmos elevation speakers, delivering dramatic overhead effects for truly enveloping audio – including Dolby Surround upmixer for legacy content.



DTS:X immersive audio formatting places sound where it would naturally occur in space, creating life-like, multi-dimensional audio. The included spatial remapping engine of DTS Neural:X™ offers improved immersion and heightened realism in all your favorite movies.







When music is encoded into a digitally compressed format like MP3, the frequency response suffers. Yamaha’s Compressed Music Enhancer employs sophisticated digital signal processing using exclusive algorithms to restore what was lost, so the music always sounds the way it should.




New circuit achieves more than doubled slew rate and it would contribute a precise signal transmission, effective for high resolution audio signal. Generally high slew rate amplifier causes unstable signal transmission, Yamaha’s newly designed circuit achieves high slew rate with stable signal transmission.



Qualcomm® QCS407 is designed to provide truly superior audio performance, with support for Dolby Atmos and DTS:X immersive home audio, as well as a dedicated high-performance audio DSP.

Incorporating the SABRE ES9007S Premier Audio DAC from ESS Technology to achieve an exceptional signal-to-noise ratio and up to 120 dB of dynamic range, this AV receiver produces professional quality digital audio.





The newly designed Anti Resonance Technology (A.R.T.) Wedge is a fifth foot in the front-and-center of the chassis unit base. It dampens much more vibrations from the power transformer, power transistors and heat sinks, as well as vibrations that might be caused by the sound from the speakers — providing dynamic sound and focused, accurate reproduction.





The highly logical and symmetrical internal layout of parts and totally renewed circuit boards are designed to keep the signal paths on each board as short as possible. The new H-cross frame improves rigidity of the receiver body and sound stability, allowing for a more clear, sharp and transparent reproduction. Also the newly redesigned mechanical structure contributes to avoiding the transition of vibration from the transformer to the amplifier circuit. Sound noises are reduced to improve clarity.





HDR10+ signals not only dynamic range (the ratio of light to dark) of video content on a scene-by-scene (or even frame-by-frame) basis, it also provides, in a small amount of metadata, the scene characteristics between bright and dark so that important detail can remain. This enables displays to reproduce images more realistically, adhering to the creator’s intent.





Supports end-to-end 8K/4K resolutions and higher refresh rate solutions with a single upgraded cable for seamless integration within the HDMI eco-system.8K delivers a super-immersive viewing experience with 2x the horizontal and vertical resolution of 4K, and 4 times as many pixels; and combined with 60Hz refresh rate enables smooth and sharp viewing of content with high-speed action. 4K/120Hz enables ultra-fast motion UHD images to be crisp and razor sharp; allowing sports, action movies, high-performance gaming and VR to benefit significantly.





Enhanced gaming and media features ensure an added level of smooth and seamless motion and transitions for gaming, movies and video. They include: Auto Low Latency Mode (ALLM) enables the ideal latency setting to automatically be applied, allowing for smooth, lag-free and uninterrupted viewing and interactivity. Variable Refresh Rate (VRR) reduces or eliminates lag, stutter and frame tearing for more fluid and detailed gameplay.

*YAMAHA initially intended to support QMS (Quick Media Switching) within the HDMI 2.1 specification. However, YAMAHA later discovered that these models cannot be updated to support QMS via firmware. This is due to an unforeseen hardware limitation caused by QMS specification change in HDMI 2.1a. This hardware limitation affects current AV receivers, including Yamaha. (Information corrected in May 2023)





YPAO-R.S.C. (Reflected Sound Control) analyses the room acoustics with the included YPAO microphone to tune your system for the best sound in your unique room. It employs R.S.C. to correct early reflections for studio-quality surround sound. YPAO 3D provides automatic sound parameter optimisation that maximises the 3D sound field effectiveness of SURROUND:AI as well as Dolby Atmos and DTS:X. 64-bit high precision EQ calculation achieves the most natural room acoustics possible.





Combine this AV receiver with the MusicCast 50 or MusicCast 20 wireless streaming speaker and enjoy the amazing convenience of creating a home theatre with wireless surround sound. What’s more, you get stunningly realistic sound with a clean, clutter-free setup. Easily turn your current living room into a special entertainment environment where you can fully enjoy movies and music.





Use your smartphone or tablet together with the MusicCast CONTROLLER app to operate the AVR and change settings quickly and easily. The same Controller app functions as a remote control for all your MusicCast-compatible devices as well as full multi-room audio controls.





Touch or voice control – the choice is yours. Intuitively control a single MusicCast product or an entire whole-of-home system with ease using Alexa or Google Assistant and hear your home come alive.

*Availability of voice command control via Amazon Alexa and Google Assistant varies by region.

*A third party device is required to initiate voice commands.





No worries, no confusion. Use this special app to receive expert set up assistance for your AV receiver and source devices. It even guides you through various other settings such as speaker connections, TV and source device connections and power amplifier assignments.





Explore a world of music with music streaming services* built-in. Synchronizing your playlists and tracks from your smart phone or computer to the AV receiver, music streaming services make it impossibly easy to either listen to your favorites or discover new music.

*Music streaming service availability varies by region.





Unlock the full potential of your 4K content. Enhanced Audio Return Channel (also known as eARC) is the next generation of ARC – available in the industry-leading AV receivers from Yamaha.

eARC delivers full-resolution, multi-channel audio formats such as Dolby® TrueHD and DTS-HD® through your existing HDMI connection, giving you the most realistic surround sound experience for immersing yourself in your favorite movies and moments.

Amplifier SectionChannel7.2
Rated Output Power (1kHz, 1ch driven)135 W (8 ohms, 0.9% THD)
Rated Output Power (20Hz-20kHz, 2ch driven)110 W (8 ohms, 0.06% THD)
Maximum Effective Output Power (1kHz, 1ch driven)165 W (8 ohms, 10% THD)
High Slew Rate AmplifierYes
Surround Sound ProcessingSurround:AIYes
CINEMA DSPYes (HD3)
DSP Programs24
Dialog Level AdjustmentYes
Virtual Presence SpeakerYes
Virtual Surround Back SpeakerYes
Dialogue LiftYes
SILENT CINEMA / Virtual CINEMA DSPYes
Dolby AtmosYes
Dolby Atmos Height VirturalizerYes
Dolby TrueHDYes
Dolby Digital PlusYes
Dolby SurroundYes
DTS:XYes
DTS-HD Master AudioYes
Auro 3DN/A
Audio FeaturesFile FormatMP3 / WMA / MPEG-4 AAC, ALAC: up to 96 kHz / 24-bit, FLAC: up to 384 kHz / 24-bit, WAV / AIFF: up to 384 kHz / 32-bit, DSD: up to 11.2 MHz
Pure DirectYes
Compressed Music EnhancerYes
High-resolution Music EnhancerYes
YPAO multi-point measurementYes with R.S.C. (Reflected Sound Control) , 3D, 64-bit High Precision EQ Calculation and Angle Measurement
YPAO VolumeYes
Adaptive DRC (Dynamic Range Control)Yes
Initial Volume & Maximum Volume SettingYes
A.R.T. WedgeYes
Bi-amp capabilityYes
Audio DelayYes (0-500 ms)
DA Converter384 kHz / 32-bit ESS Hyperstream DAC ES9007S
Video FeaturesHDMI eARCYes
HDMI Audio Return ChannelYes
HDMI Pass-through8K60AB, 4K120AB, 40GBPS (via future update)
HDMI Up-scalingYes, up to 8K (via firmware update)
HDMI Up-conversionN/A
Dolby VisionYes
HDR 10+Yes (via firmware update)
VRR/ALLM/QMS/QFTYes (via firmware update)
Video adjustmentN/A
ConnectivityMusicCast SurroundYes
HDMI Input/Output7 / 3 (HDMI2.1 / HDCP2.3)
HDMI CECYes
USB InputYes
Network PortYes
Wi-FiYes (2.4 / 5 GHz)
AirPlay 2Yes
BluetoothYes (SBC / AAC)
Front AV InputUSB
Digital Audio Input/Output: Optical2 / 0
Digital Audio Input/Output: Coaxial1 / 0
Analog Audio Input/Output4 / 0
Phono InputYes
XLR TerminalN/A
Component Video Input/OutputN/A
Composite Video Input/OutputN/A
Preout7.2-ch
Headphone Output1
Tuner SectionFM/AM TunerYes (Availability varies by region.)
DAB TunerYes (Availability varies by region.)
User InterfaceOn-screen displayGraphical User Interface
SCENESCENE PLUS (8 sets)
App ControlYes (iPhone / iPad / Android phone / tablet)
Web Browser ControlYes
Remote Control UnitYes
Zone ControlZone 2 Audio OutputPreout / HDMI
Zone 3 Audio OutputN/A
Zone 4 Audio OutputN/A
Powered ZoneZone 2
Zone Video OutputHDMI
Zone B OutputN/A
Zone GUIN/A
RS-232C InterfaceN/A
+12V Trigger Output2
Remote (IR) Input/Output1 / 1
Party ModeYes
GeneralStandby Power Consumption (IR only)<0.4 W
Auto Power StandbyYes
ECO modeYes
Dimensions (W x H x D)435 W x 191 H x 442 D mm (with antenna up:435 W x 270 H x 442 D mm);17-1/8"W x 7-1/2"H x 17-3/8"D (with antenna up:17-1/8"W x 10-5/8"H x 17-3/8"D)
Weight16.2 kg; 35.7 lbs.
